MICSIG STO1102C+ Oscilloscope 2x100MHz
2x 100MHz
Tablet format usable in the laboratory as well as in the field with its battery option
Mixed ergonomics: the speed and interactivity of the touch screen, combined with the precision of the settings by buttons
8-inch high-resolution 800 x 600 pixel color display, 256 levels of intensity
Refresh of 80,000 curves/s
Memory depth: up to 28 Mpts
Sensitivity from 1 mV/div to 10 V/div.
31 automatic measurements
Sampling rate 1 GS/s max.
Math functions +, -, /, x and FFT (RMS or dBV)
8 GB internal memory for storing curves, screen copies, and settings
Communication: USB 2.0 port (possibility to connect a mouse) and WiFi as standard
Supplied as standard with lithium-ion battery, HDMI (for video projector, for example), serial bus decoding software, screen protector and carrying strap.
Dimensions / Weight: 280 x 180 x 55 mm / 1.3 kg
Warranty: 3 years
Serial link decoding with the STO1102C+ Micsig
The strengths of the oscilloscope
Supplied with: Oscilloscope Charger power cord External charger 2 Probes BNC caps 1 strap to carry 1 screen protector 1 battery
| Nombre de voies | 2 |
| Taille de l'écran | 8" |
| Bande passante | 100 MHz |
| Générateur intégré | Non |
| Upgradable MSO | Non |
| Garantie | 3 ans |
| Profondeur mémoire | 28 Mpts |
| Échantillonnage monocoup | 1 Géch/s |
| Interface | USB |
-
